7. Specifications
7. Specifications
7.1 IX-NNN2515H/3515H
IX-NNN2515H (Arm Length 250, Standard Specification)
Item
Specifications
Type
IX-NNN2515H-
L-T1
Degree of freedom
Four degrees of freedom
Overall arm length
250
Arm 1 length
125
Arm 2 length
mm
125
Axis 1 (arm 1)
AC servo motor + Speed reducer
Axis 2 (arm 2)
AC servo motor + Speed reducer
Axis 3 (vertical axis)
AC servo motor with brake + Belt + Ball-screw spline
Drive method
Axis 4 (rotational axis)
AC servo motor + Belt + Reduction gear + Spline
Axis 1 (arm 1)
200
Axis 2 (arm 2)
100
Axis 3 (vertical axis)
100
Motor capacity
Axis 4 (rotational axis)
W
50
Axis 1 (arm 1)
r120
Axis 2 (arm 2)
degree
r130
Axis 3 (vertical axis) (*1)
mm
150
Movement
range
Axis 4 (rotational axis)
degree
r360
Axis 1 + Axis 2 (maximum
composite speed)
3191
Axis 3 (vertical axis)
mm/sec
1316
Maximum
operating
speed (*2)
Axis 4 (rotational axis)
degree/sec
1600
Axis 1 + Axis 2
r0.010
Axis 3 (vertical axis)
mm
r0.010
Positioning
repeatability
precision (*3)
Axis 4 (rotational axis)
degree
r0.005
Standard cycle time (*4)
sec 0.40/2
kg
Rated 1
Loading
capacity
Maximum
kg
3
Dynamic (*5)
11.0 (11.3) Push torque limit value: 70%
Push-in thrust
of axis 3
(vertical axis)
Static (*6)
N (kgf)
58.0 (5.9) Push torque limit value: 40%
Permissible moment of inertia
(*7)
kg
m
2
0.015
Permissible
load on axis 4
Permissible torque
N
m
(kgf
cm)
1.9 (19.5)
Permissible tool diameter (*8)
mm
80
Home detection
Absolute
User wiring
D-sub 15-pin connector with 15-core AWG26 shielded cable
(socket)
Alarm indicator (*9)
One small, red LED indicator (rated voltage: 24 V)
