55
8. Installation Environment and Storage Environment
8. Installation Environment and Storage Environment
8.1 Installation Environment
8.1.1 IX-NNN2515H/3515H, IX-NNC2515H/3515H
Install the robot in an environment that satisfies the following conditions:
x Away from direct sunlight
x Not subject to radiated heat from a high-capacity energy source such as a heat-treating furnace
x Surrounding air temperature: 0qC to 40qC
x Humidity: 85% or less (non-condensing)
x Not exposed to corrosive or flammable gases
x Not subject to impact or vibration
x Not exposed to a significant amount of electromagnetic waves, ultraviolet rays or radiation
x Sufficient space is available to ensure safety in teaching and maintenance/inspection operations
Generally, the robot must be installed where the operator need not wear protective gear in order to work.
8.1.2 IX-NNW2515H/3515H
The dust-proof/splash-proof specification has a structure confirming to IEC standard with regard to water and
powder dust and protection degree of IP65 or equivalent.
Install the robot in an environment that satisfies the following conditions:
Please note that the dust-proof/splash-proof specification does not provide an explosion-proof structure.
x Away from direct sunlight
x Not subject to radiated heat from a high-capacity energy source such as a heat-treating furnace
x Surrounding air temperature: 0qC to 40qC
x Humidity: 85% or less (non-condensing)
x Not exposed to corrosive or flammable gases
x Not subject to impact or vibration
x Not exposed to a significant amount of electromagnetic waves, ultraviolet rays or radiation
x Sufficient space is available to ensure safety in teaching and maintenance/inspection operations
