14

1. Name of Each Part

IX-NNC2515H/3515H

ALM (indicator)

‡4 user piping
(black, red, white; 3 locations)

Reference
surface

Top cover (arm 1)

Mechanical stopper for arm 1

Mechanical stopper for arm 2

BK SW
(Brake-release switch)

User connector

Spacer for user part installation

Axis 3

(vertical axis)

Cover (arm 2)

Axis 2

Axis 1

Panel

Axis 4

(R-axis)

Wiring duct

End cover (arm 1)

Arm 2

Arm 1

Front panel (base)

Reference surface

Base

Rear panel

(base)

T-slot for peripheral
installation (M3, M4)

Applicable tube: Outer
diameter

‡12

(Inner diameter

‡8)

Mechanical stopper for
axis 3 (vertical axis)

Ball screw spline shaft

Mechanical stopper for
axis 3 (vertical axis)

Bellows

Panel
