9
Handling Precaution
1. Positioning Repeatability Does Not
2. Make sure to attach the Horizontal Articulated Robot properly by following
this operation manual.
Change Even If the Positioning Band is
Changed.
Positioning repeatability does not change ev
Using the product with the Horizontal Articulated Robot not being certainly retained or affixed may cause
abnormal noise, vibration, malfunction or shorten the product life.
en if the positioning band is changed.
If the positioning band is narrower than the default value, the positioning repeatability does not change, but the
time it takes for the positioning complete signal to be output takes longer. The execution of next operation
instruction (e.g., MOVP, MOVL) is delayed and, as a result, the tact time of the entire cycle may be delayed.
3. Handling of the Carton
Each robot is packed with a controller prior to shipment.
When transporting the carton containing the robot and controller, observe the following items and be careful not
to drop the carton or apply impact due to forcible contact:
• If the carton is heavy, one operator should not attempt to carry it alone.
• Place the carton on a level surface if it is to be left there for a while.
• Do not climb upon the carton.
• Do not place on the carton any heavy object that may cause the carton to deform, or an article whose shape
allows a work part to be concentrated at one point.
[Carton]
Robot
Arm fixing plate
Controller, accessories and
other items (except for the robot)
