24
3. Robot Operation
Area
IX-NNW2515H (Arm Length 250, Dust-proof/Splash-proof Specification), IX-NNC2515H (Arm Length 250, Clean
Room Specification)
IX-NNW3515H (Arm Length 350, Dust-proof/Splash-proof Specification), IX-NNC3515H (Arm Length 350, Clean
Room Specification)
Area of prohibited entry Area of prohibited entry
Movement range Mechanical stopper position
Area of prohibited entry Area of prohibited entry
Movement range Mechanical stopper position
