Ransburg RCS 2 Ratio Control System - Manual (Page 74)

Error
Name Description Explanation and/or Possible Causes
Batttery
Low
No slaves
Present
Interface
SPI Fault
Network
Error
XXXXX
Opto-22
Failure
The battery that maintains the data
parameters is below the minimum op-
erating voltage.
On power up, the Interface Card could
not communicate with any of the four
(4) possible Channel Cards, referred
to as slaves on the Serial Peripheral
Interface (SPI) bus.
The Interface Card detected an error
while attempting to communicate with
a Channel Card via the Serial Periph-
eral Interface (SPI) bus.
The User - Interface Computer is not
able to communicate with the
interface card.
The User - Interface Computer is not
able to communicate with the color
change sequencer brain.
1. The power to the Interface Card may have
been off for too long resulting in premature
failure of the battery.
1. There are no Channel Cards inserted into
the card rack and mother board (backplane).
2. The SPI bus device on the Interface Card
may not be functioning.
3. One of the SPI bus devices on a Channel
Card may not be functioning in such a way
as to prevent communications by any other
Channel Card.
1. This error may occur when the system is
first powered up and may be ignored.
1. Check for power on the rack (E-Stop button
out)?
2. Check all Ethernet cables, switches, etc.
1. Check for power on the motor amp panel.
2. Check all Ethernet cables, switches, etc.
Source
Interface
Card
Interface
Card
Interface
Card
User -
Interface
Computer
User -
Interface
Computer
APPENDIX K: ERROR CODES (Continued)
RCS-2 User Manual - Appendix
71 LN-9407-00.2
Ransburg
