APPENDIX K: ERROR CODES (Continued)
Error
Name Description
Explanation and/or Possible Causes
Pot Life
Expired
System
Over
Pressure
Channel
Card
Parameter
Fault
Channel
Card SPI
Fault
Channel
Card
Internal
Fault
Mixed material in the applica-
tor fluid line has remained be-
yond the Pot Life Time speci-
fied in the Job Configuration.
Either the Pump Outlet or
Inlet pressure exceeded the
Over-Pressure Limit specified
in the System
Configuration.
Invalid parameter entered in
either the Channel or Job
Configuration.
No communication via the Se-
rial Peripheral Interface (SPI)
bus has occurred between the
Interface Card and Channel
Card for more than one seond.
The timer interrupt service rou-
tine is unable to execute the
required firmware logic in the
time between time interrupts.
1.Mixed material has remained in the applicator fluid
line beyond the Pot Life Time specified in the Job
Configuration.
2. The Flow Rate Setpoint specified in the Job Con-
figuration, or via the Remote Analog Setpoint, or
via Remote I/O, is not high enough to move the
Mixed Volume specified in the Gun Configuration
during the Pot Life Time specified in the Job Con-
figuration.
1. Failure of the E/P transducer that controls the pump
inlet pressure.
2. Failure of the pressure regulator that
controls the pump inlet pressure.
3. Restriction in the fluid line.
4. For Automatic guns, failure of applicator trigger
valve.
5. Over-Pressure Limit value specified in the System
Configuration is too low.
1. Hardener No Flow value specified in the Slave
Channel Configuration is less than 4.0 milliamps.
2. Hardener Flow On value specified in the Slave
Channel Configuration is greater than 20.0 milli-
amps.
3. Hardener No Flow value specified in the Slave
Channel Configuration is greater than Hardener
Flow On value specified in the Slave Channel
Configuration.
4. Any Minimum Pressure or Maximum Pressure
value specified in the Channel Configuration or
Feather Pressure specified in the Job Configuration
exceeds the Over Pressure Limit value specified
in the System Configuration.
1. Interface Card is no longer functioning.
2. Failure of the mother board (backplane).
3. A firmware bug is preventing service of the SPI
bus communications.
1. A firmware bug is preventing completion of required
logic in the time between timer interrupts.
Source
Channel
Card
Channel
Card
Channel
Card
Channel
Card
Channel
Card
