way, totalization data and PID parameters relate
directly to the material. These parameters include:
• Ratio
• Flow Rate Setpoint
• Max. Flow Rate
• Min. Flow Rate
• Bar Graph Limit
• Pot Life Timer
• Feather Pressure
• Fill Volume
• Pressure Pot Capacity
• Delta Pressure
• Min. Inlet Fluid Pressure
• Min. Inlet Control Pressure
• Inlet Cont. Pressure Kp
• Inlet Cont. Pressure Ki
• Inlet Cont. Pressure Kd
• Inlet Cont. Pressure Db
• Hardener Sample Time
• Hardener No Flow Limit
• Hardener Flow On Limit
Alarm Configuration Parameters allow the
user to specify what conditions cause a "spray
shutdown" to occur. They include:
• Input Under Pressure
• Input Over Pressure
• Output Under Pressure
• Output Over Pressure
• Flow Out of Tolerance
• Hardener Flow Loss
• Pressure Pot Empty
• Inlet Pressure Loss
• Outlet Pressure Loss
• Analog Remote Loss
• Ratio Out of Tolerance
• Motor Amp Fault *
• Analog Feather Loss
• Foldback Pressure Reached
• Pot Life Expired
• System Over Pressure *
• Channel Card Parameter Fault *
• Channel Card SPI Fault *
• Channel Card Internal Fault *
Gun Parameters are parameters that affect the
gun. These parameters apply to all channels
configured to that gun. They include:
• Mode (manual or automatic)
• Number of channels configured to gun
• Master Channel Number
• Slave Channel Number
• Default Job Number
• Number of Applicators
• Default Job Number
• Mixed Volume
• Tolerance Percentage
• Tolerance Volume
• Tolerance Time
• Solvent Pulses Per Liter
• Horn Code
• Auto Reset
Channel Parameters are parameters that affect
only that specific channel. For two channel guns,
there are independent parameters for each of the
two channels. They include:
• Fill Enable/Disable
• Trigger On-Delay Time
• Trigger Off-Delay Time
• Pump Size
• Pump Pulses Per Liter
• Maximum Pump Speed
• Miniumum Pump Speed
• Maximum Inlet Fluid Pressure
• Minimum Inlet Fluid Pressure
• Maximum Outlet Fluid Pressure
• Minimum Outlet Fluid Pressure
• Inlet Pressure Sensor Enable/Disable
• Foldback Kp
• Foldback Ki
• Foldback Kd
• Foldback Deadband
• Feather Kp
• Feather Ki
• Feather Kd
• Feather Deadband
Job Parameters are parameters that are stored
with the specific job number. Typically, a job
number is assigned to a specific material. In this
>
Items above marked with an asterisk (*)
cannot be disabled.
NOTE
