Channel Parameters are parameters that affect
only that specific channel. For two channel guns,
there are independent parameters for each of the
two channels. They include:
• Fill Enable/Disable
• Trigger On-Delay Time
• Trigger Off-Delay Time
• Pump Size
• Pump Pulses Per Liter
• Maximum Pump Speed
• Miniumum Pump Speed
• Maximum Inlet Pressure
• Minimum Inlet Pressure
• Maximum Outlet Pressure
• Minimum Outlet Pressure
• Inlet Pressure Sensor Enable/Disable
• Foldback Kp
• Foldback Ki
• Foldback Kd
• Foldback Deadband
• Feather Kp
• Feather Ki
• Feather Kd
• Feather Deadband
Job Parameters are parameters that are stored
with the specific job number. Typically, a job
number is assigned to a specific material. In this
way, totalization data and PID parameters relate
directly to the material. These parameters include:
• Ratio
• Flow Setpoint
• Maximum Flow (for analog control)
• Minimum Flow (for analog control)
• Bar-Graph Limit
• Pot-Life Time
• Feather Pressure
• Fill Volume
• Pressure Pot Capacity
• Pressure Differential (across the pump)
• Minimum Pressure
• Inlet Presure Control PID Parameters
• Hardener Sample Time
• Hardener No Flow Setpoint
• Hardener Flow On Point
Alarm Configuration Parameters allow the
user to specify what conditions cause a "spray
shutdown" to occur. They include:
• Input Under Pressure
• Input Over Pressure
• Output Under Pressure
• Output Over Pressure
• Flow Rate Out of Tolerance
• Hardener Flow Loss
• Pressure Pot Empty
• Inlet Pressure Loss
• Analog Remote Loss
• Ratio Out of Tolerance
• Motor Amp Fault *
• Analog Feather Loss
• Analog Spare Loss
• Foldback Pressure Reached
• Pot Life Expired
• System Over Pressure *
• Channel Card Parameter Fault *
• Channel Card SPI Fault *
>
Items marked with an asterisk (*) can-
not be disabled
NOTE
