4.3 MAIN MENU
The following information is displayed within the Main Menu:
Measured Value: This is displayed as Level, distance or
volume in the required engineering unit chosen within the
calibration menu - see next section.
Gas Temperature: This is a display of the temperature of
the gas in the engineering unit selected within the calibration
menu.
If ‘ --- °C‘ is displayed within this option the measured tempe-
rature is out of range.
(Range -40 to +95°C)
Output Signal: The standard output signal range is propor-
tional to the selected measuring range.
(Range 4.00mA to 20.00mA with a 22mA error signal).
- The units will blink while the transmitter is performing an internal calculation.
- The whole display will blink when the signal has been lost or in cases of an electronic
failure.
1.455 M
24.2 °C
16.45 MA
0......9
