8175
ENGLISH
QUICKSTART
2.1 INSTALLATION
Pay attention to the installation of the transmitter to ensure the proper
operating of the device.
Select the mounting position by respecting the following instructions:
Protect the device against bad weather and temperature changes:
This section provides a comprehensive installation and operation guide which will assist
with the commissioning of the 8175 Level Transmitter.
min. 30 cm
H
H
≅
R/2
≅
R/2
min. 30 cm
Mounting on a closed tank
min. 30 cm
H
D
Mounting on a shaft
Protection when installed outside
D [mm]
65
80
100
H [mm]
100
250
400
