6.2 HORIZONTAL CYLINDRICAL TANK VALUE CONVERSIONS
For the calculation and input of the measured values for a horizontal cylindrical tank, both
the level % and Volume % relationships have to be calculated and then entered within the
manual input of distances and associated volumes procedure.
To calculate the values a table below has been provided to assist with the calculations.
Steps for value calculation
- Identify the maximum and minimum level and volume for the application.
- Enter the maximum (100%) and minimum (0%) volume and level within the table.
- Calculate the level values at the respective level percentages for the application
(90% - 0%).
- Calculate the volume values for the respective volume percentages by multiplying
the maximum volume of the application by the volume % within the table and
dividing by 100.
After calculating the values perform a volume Teach-In - D.
Level in % Level (chosen unit) Volume in % Volume (chosen
unit)
0 0,00
10 5,20
20 14,24
30 25,23
40 37,35
50 50,00
60 61,64
70 74,77
80 85,76
90 94,79
100 100,00
