6.6 TYPE SPECIFICATION
1)
M20x1,5 = cable gland for cables with ø 6-12 mm
2)
M16x1,5 = cable gland for cables with ø 4-8 mm
Power supply
Relays
Mounting thread
Electrical connection
Order code
18-32 VDC
No
G 2’’
EN 175301-803
430822
18-32 VDC
No
G 2’’
2 x M20x1,5
1)
430823
18-32 VDC
2
G 2’’
2 x M20x1,5
1)
430824
115/230 VAC
No
G 2’’
2 x M20x1,5
1)
430825
115/230 VAC
2
G 2’’
2 x M20x1,5
1)
430826
Power supply
Relays
Mounting thread
Electrical connection
Order code
18-32 VDC
No
NPT 2’’
EN 175301-803
430827
18-32 VDC
No
NPT 2’’
2 x NPT 1/2’’
430828
18-32 VDC
2
NPT 2’’
2 x NPT 1/2’’
430829
115/230 VAC
No
NPT 2’’
2 x NPT 1/2’’
430830
115/230 VAC
2
NPT 2’’
2 x NPT 1/2’’
430831
Transmitter 8175, compact, with 4-20 mA output, North-american versions
Power supply
Relays
Electrical connection
Order code
18-32 VDC
No
Terminal strip
436567
18-32 VDC
2
Terminal strip
436568
Transmitter 8175, panel-mounted, with 4-20 mA output, Worldwide and North-
American Versions
Power supply
Relays
Electrical connection
Order code
18-32 VDC
No
5 x M16x1,5
2)
436569
18-32 VDC
2
5 x M16x1,5
2)
436570
115/230 VAC
No
5 x M16x1,5
2)
437339
115/230 VAC
2
5 x M16x1,5
2)
437340
Transmitter 8175, wall-mounted, with 4-20 mA output, Worldwide and North-
American Versions
Mounting thread
Cable
length
Electrical connection
Order code
G 2’’
10 m
1 x M16x1,5 + 1 x M20x1,5
3)
436563
G 2’’
20 m
1 x M16x1,5 + 1 x M20x1,5
3)
436564
NPT 2’’
10 m
1 x M16x1,5 + 1 x M20x1,5
3)
436565
NPT 2’’
20 m
1 x M16x1,5 + 1 x M20x1,5
3)
436566
Sensor 8170, Worldwide and North-American Versions
Transmitter 8175, compact, with 4-20 mA output, Worldwide versions
3)
M20x1,5 = cable gland for cables with ø 6-12 mm
M16x1,5 = cable gland for cables with ø 4-8 mm
