67
8175
ENGLISH
INFORMATION
Position Description Order code
1 PC cover with screws and window 553189
Cover with screws, front foil and electronic board for panel version without
relay
448821
Cover with screws, front foil and electronic board for panel version with relays 448822
2 Housing for version with plug EN 175301-803 448392
Housing for version with 2 M20x1,5 cable glands 430833
Housing for wall-mounted version without relay nor electronic board 448823
Housing for wall-mounted version with relays, without electronic board 448824
3 FPM gasket 448818
EPDM gasket 448819
4 Sensor for fitting G2” 448394
Sensor for fitting NPT 2” 448817
5 Cable plug EN 175301-803, with cable gland (type 2508) 438811
6 Cable plug EN 175301-803 with NPT 1/2‘‘ reduction (type 2509) 162673
7+9+10+12 Set incl. 2 x M20x1,5 cable glands
+ 2 neoprene flat gaskets for cable glands or screwed plugs
+ 2 x M20x1,5 screwed plugs
+ 2 multiway seals, 2x6 mm 449755
8+9+10 Set incl. 2 x M20x1,5 / NPT1/2’’ reductions (mounted gasket)
+ 2 neoprene flat gaskets for screwed plugs
+ 2 x M20x1,5 screwed plugs 551782
10+11+12 Set incl. 1 x M20x1,5 cable gland obturator
+ 1 multiway seal, 2x6 mm, for cable glands
+ 1 black EPDM gasket (unused)
+ 1 mounting instruction sheet 551775
Power supply board, 115/230 VAC, for compact transmitter 448393
Power supply board, 115/230 VAC, for wall-mounted transmitter 448827
Electronic board for a compact transmitter without relay 553175
Electronic board for a compact transmitter with relays 553176
Electronic board for a wall-mounted transmitter without relay 448825
Electronic board for a wall-mounted transmitter with relays 448826
PC nut 619204
Mounting set for the panel-mounted version 448820
