50
8175
ENGLISH
TEST MENU
4.5 TEST MENU
PRESS
0......9
ENTER
SIMULTANEOUSLY FOR 5 SECONDS
The following parameters are selected and set within this menu:
The following sections explain how to change and investigate the parameter values within
the test menu above.
0......9
OFFSET
SPAN
SIGNAL
T° ADJUST
END
SIMUL
RESET
Function Section
Zero point compensation (4 mA). 4.5.1
Span compensation (20 mA). 4.5.2
Temperature correction +/- 15
°C .
4.5.3
Display of the returned signal strength. 4.5.4
Input of the level, volume or temperature to be si-
mulated. The current and relay outputs will react
according to this value. 4.5.5
Reset of the device to the factory settings and
resetting of the echo filtering table (see 4.4.5). 4.5.6
Return to the main menu and store the new para-
meters. If one of the two values for OFFSET and
SPAN is inappropriate, the device will automa-
tically return to the «OFFSET» parameter and new
values must be entered.
