9 Notes on installation

9.1 Alarm

centre

Fix the alarm centre to a flat, dry, vibration-free and heat-
resistant surface. The cables for the power supply of the
alarm centre, the alarm zones and the signalling
equipment (siren, flashlight, any external loudspeakers,
etc.) should be inconspicuous, if possible below the
surface or in a cable channel.

• Open the alarm centre housing (loosen the screws with

a Philips screwdriver and remove the cover).

• The alarm centre’s PCB is fixed in the housing with

three screws. Loosen these screws and remove the
PCB. The transformer plug can be disconnected from
the PCB.


• Use the housing as a template to make drill-marks for

the fixing-screws.


• At the marked positions, drill three holes (min. 4mm Ø,

4.5cm long).

• Fix the alarm centre housing and feed the cables into

the housing.

• Do not tighten the fixing screws until you have

connected all the cables. Replace the PCB and close
the housing by replacing the cover.

9.2 Control

units

The control units should also be mounted on a flat, dry,
vibration-free surface. The mounting height is important.
The units should be positioned so that all users can easily
read the display and operate the buttons.

• Open the cover of the control unit and loosen the

screws on the base.


• Use the housing as a template to make drill-marks for

the fixing-screws.

• At the marked positions, drill three holes (min. 4mm Ø,

3cm long).

• Connect the control unit to the alarm centre (see next

page).


• Connect the control unit to the external components.

• Make any settings necessary in the control unit.

• Mount the control unit housing on the wall. Replace the

front plate containing the control unit PCB and tighten
the fixing screws.
