30

UK

14 First-time usage

If you want to create your own configuration of the system
and do not need the example of installation pay attention
to the next steps. Please take notice of the important
terms concerning the alarm panel. You can now put the
alarm panel into operation.

1. Connect the 12V battery (7.0 Ah) to the

contacts of the alarm centre (note the colour
code:
red = +12V, black = 0V).

2. Using a screwdriver, short-circuit the two pins of

the kick-start jumper (see p. 14).

3. The green LED for the power supply (

)

begins to flash and the buzzers of the control
units can be activated. You can ignore the
display messages.

4. Enter the factory-set user code.

This is:

1234

. You can ignore the display

messages.

5. First close the housing of the burglar alarm

panel securely before switching on the 230V
voltage.

6. Switch on the 230V mains voltage to the burglar

alarm panel.

7. The green LED for the voltage (

) now lights

constantly.

8. Now enter via the control unit:

0

and then the

factory-set programming code

7890

The display shows: PROGR. MODE

9. You are now in the program menu of the burglar

alarm panel and can start programming

.
