16 Technical data
Voltage supply
External
voltage
supply: 230V
AC +/-10% (ambient temperature 20°C)
External
power
consumption:
200mA
maximum
Internal
voltage
supply:
19VAC
/
-10%
Internal
power
supply:
1.0A
maximum
CPU
power
consumption:
150mA
maximum
Power consumption of control unit:
35mA maximum
Emergency power supply:
12V DC, 7.0Ah lead rechargeable battery
Outputs
Transistor
outputs:
12V
DC, 0.5A maximum, negative switching
Loudspeaker:
2
x
16
Ohm
loudspeakers
parallel
AUX:
12V DC / 0.5A maximum
Relay
outputs:
24V
DC
/
1A
maximum
Additional
Transistor
outputs:
12VDC,
0.05A
max.
Inputs
TR:
Tamper
input
from
siren
Fuses
F1
–
12V
AUX:
230V,
1A
quick-acting
F2
–
battery:
230V,
2A
quick-acting
Specifications
Dimensions:
243mm
x
234mm
x
95mm
(HxWxD)
Weight:
2.45kg
Internal
time:
+/-
10
min./year,
synchronised
to
mains
frequency
Environment:
-10°C
to
+55°C
max.
75%
humidity
