Exit mode for Internal C (072

n

)

Menu item

Setting

Meaning

072

0

Exit time plus quiet tone

1

Immediate

2

Silent

3

As exit mode for overall
activated

Alarm behaviour at Internal C (073

n

)

Menu item

Setting

Meaning

073

0 Control

unit

1

Loudspeaker and control
unit

2

Local

Alarm

3

External

Alarm

(control

unit + siren and dialler)

Exit time at Internal C (075

n

)

Menu item

Setting

Meaning

075

1 10

sec

2

20

sec

3

30

sec

4

45

sec

5

60

sec

6

120

sec

Exit mode for Internal D (076

n

)

Menu item

Setting

Meaning

076

0

Exit time plus quiet tone

1 Immediate

2 Silent

3

As exit mode for overall
activated

Alarm behaviour at Internal D (077

n

)

Menu item

Setting

Meaning

077

0 Control

unit

1

Loudspeaker and control
unit

2

Local

Alarm

3

External Alarm (siren and
dialler)



Exit time at Internal D (079

n

)

Menu item

Setting

Meaning

079

1 10

sec

2

20

sec

3

30

sec

4

45

sec

5

60

sec

6

120

sec

Behaviour of Transistor output 1

(081

nn

)

Menu item

Setting

Meaning

081

00 Siren

01

Input/output to follow

02

Active to follow

03 Active

stable

04

Shock sensor reset

05 Walk

test

06

Ready to follow

07 24

hours

08

Flash to follow

09 Fire

reset

10

Siren test (self setting)

11 Active

acknowledgement

12 Active

pulse

1

13

Inactive pulse 1

26 Active

pulse

1

27 Active

pulse

2

28 Active

pulse

3

29 Active

pulse

4

30

Inactive pulse 1

31

Inactive pulse 2

32

Inactive pulse 3

33

Inactive pulse 4

34 Fire

35 Panic

Behaviour of Transistor output 2

(082

nn

)

Menu item

Setting

Meaning

082

See setting

for transistor output 1
