Behaviour of Additional Switch Output 1
(151
nn
)
Menu item
Setting
Meaning
151
00 Not
used
01
Fire to follow
02
Panic to follow
03
Burglary to follow
04
Active/inactive to follow
05 Alarm
cancellation
06 Technical
alarm
11 Network
fault
12
Sabotage to follow
13
Active to follow
14
Inactive to follow
15 Zone
locked
16
Emergency alarm to
follow
17 Keybox
18 Anti-mask
19 Fire
alarm
30 Active
pulse
1
31 Active
pulse
2
32 Active
pulse
3
33 Active
pulse
4
34
Inactive pulse 1
35
Inactive pulse 2
36
Inactive pulse 3
37
Inactive pulse 4
Behaviour of Additional Switch Output 2
(152
nn
)
Menu item
Setting
Meaning
152
See setting
for switch output 1
Behaviour of Additional Switch Output 3
(153
nn
)
Menu item
Setting
Meaning
153
See setting
for switch output 1
Behaviour of Additional Switch Output 4
(154
nn
)
Menu item
Setting
Meaning
154
See setting
for switch output 1
Behaviour of Additional Switch Output 5
(155
nn
)
Menu item
Setting
Meaning
155
See setting
for switch output 1
Behaviour of Additional Switch Output 6
(156
nn
)
Menu item
Setting
Meaning
156
See setting
for switch output 1
Behaviour of Additional Switch Output 7
(157
nn
)
Menu item
Setting
Meaning
157
See setting
for switch output 1
Behaviour of Additional Switch Output 8
(158
nn
)
Menu item
Setting
Meaning
158
See setting
for switch output 1
Inversion of additional switch outputs
(159
n
)
Menu item
Setting
Meaning
159
0 Not
inverted
(+ve removed)
1
Inverted
(+ve applied)
Duration of active pulse 1 2 3 4
(170
n
n
n
n
)
Menu item
Setting
Meaning
170
00 Latched
output
01 – 12
Pulse duration in
seconds
Switch output active stable
(171
n
n
n
n
)
Menu item
Setting
Meaning
171
A B C D
Activate switch output
for active area
