Recommended max. fuse*
[kW] Max. prefuse
Bussmann
E52273
RK1/JDDZ
Bussmann
E4273 J/JDDZ
Bussmann
E4273 T/JDDZ
SIBA E180276
RK1/JDDZ
LittelFuse
E81895
RK1/JDDZ
Ferraz-
Shawmut
E163267/E2137
RK1/JDDZ
Ferraz-Shawmut
E2137 J/HSJ
11 30 A KTS-R-30 JKS-30 JKJS-30 5017906-030 KLS-R-030 A6K-30-R HST-30
15-18.5 45 A KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45-R HST-45
22 60 A KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60-R HST-60
30 80 A KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80-R HST-80
37 90 A KTS-R-90 JKS-90 JJS-90 5014006-100 KLS-R-090 A6K-90-R HST-90
45 100 A KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100-R HST-100
55 125 A KTS-R-125 JKS-125 JJS-125 2028220-125 KLS-150 A6K-125-R HST-125
75 150 A KTS-R-150 JKS-150 JJS-150 2028220-150 KLS-175 A6K-150-R HST-150
* UL compliance 525-600V only
Table 10.19 525-690 V, Frame Sizes B and C
10.3.3 Substitute Fuses for 240 V
Original fuse Manufacturer Substitute fuses
KTN Bussmann KTS
FWX Bussmann FWH
KLNR LITTEL FUSE KLSR
L50S LITTEL FUSE L50S
A2KR FERRAZ SHAWMUT A6KR
A25X FERRAZ SHAWMUT A50X
Table 10.20 Substitute Fuses
10.4 Connection Tightening Torques
Power (kW) Torque (Nm)
Enclo-
sure
200-240 V 380-480/500 V 525-600 V 525-690 V Mains Motor
DC
connection
Brake Earth Relay
A2 1.1-2.2 1.1-4.0 1.8 1.8 1.8 1.8 3 0.6
A3 3.0-3.7 5.5-7.5 1.1-7.5 1.1-7.5 1.8 1.8 1.8 1.8 3 0.6
A4 1.1-2.2 1.1-4.0 1.8 1.8 1.8 1.8 3 0.6
A5 1.1-3.7 1.1-7.5 1.1-7.5 1.8 1.8 1.8 1.8 3 0.6
B1 5.5-11 11-18 11-18 1.8 1.8 1.5 1.5 3 0.6
B2 15 22-30 22-30 11-30 4.5 4.5 3.7 3.7 3 0.6
B3 5.5 -11 11-18 11-18 1.8 1.8 1.8 1.8 3 0.6
B4 15-18 22-37 22-37 11-37 4.5 4.5 4.5 4.5 3 0.6
C1 18-30 37-55 37-55 10 10 10 10 3 0.6
C2 37-45 75-90 75-90 37-90 14/24 1) 14/24 1) 14 14 3 0.6
C3 45-55 45-55 45-55 10 10 10 10 3 0.6
C4 37-55 75-90 75-90 14/24 1) 14/24 1) 14 14 3 0.6
Table 10.21 Tightening of Terminals
1) For different cable dimensions x/y, where x
≤ 95 mm
2 and y
≥ 95 mm
2 .
