No. Description Warnin
g
Alarm/Trip Alarm/Trip Lock Parameter Reference
16 Short Circuit X X
17 Control word timeout (X) (X) 8-04 Control Timeout Function
18 Start Failed X 1-77 Compressor Start Max
Speed [RPM], 1-79 Compressor
Start Max Time to Trip,
1-03 Torque Characteristics
23 Internal Fan Fault X
24 External Fan Fault X 14-53 Fan Monitor
25 Brake resistor short-circuited X
26 Brake resistor power limit (X) (X) 2-13 Brake Power Monitoring
27 Brake chopper short-circuited X X
28 Brake check (X) (X) 2-15 Brake Check
29 Drive over temperature X X X
30 Motor phase U missing (X) (X) (X) 4-58 Missing Motor Phase
Function
31 Motor phase V missing (X) (X) (X) 4-58 Missing Motor Phase
Function
32 Motor phase W missing (X) (X) (X) 4-58 Missing Motor Phase
Function
33 Inrush fault X X
34 Fieldbus communication fault X X
35 Out of frequency range X X
36 Mains failure X X
37 Phase Imbalance X X
38 Internal fault X X
39 Heatsink sensor X X
40 Overload of Digital Output Terminal 27 (X) 5-00 Digital I/O Mode,
5-01 Terminal 27 Mode
41 Overload of Digital Output Terminal 29 (X) 5-00 Digital I/O Mode,
5-02 Terminal 29 Mode
42 Overload of Digital Output On X30/6 (X) 5-32 Term X30/6 Digi Out (MCB
101)
42 Overload of Digital Output On X30/7 (X) 5-33 Term X30/7 Digi Out (MCB
101)
46 Pwr. card supply X X
47 24V supply low X X X
48 1.8V supply low X X
49 Speed limit X (X) 1-86 Trip Speed Low [RPM]
50 AMA calibration failed X
51 AMA check U
nom
and I
nom
X
52 AMA low I
nom
X
53 AMA motor too big X
54 AMA motor too small X
55 AMA Parameter out of range X
56 AMA interrupted by user X
57 AMA timeout X
58 AMA internal fault X X
59 Current limit X
60 External Interlock X
62 Output Frequency at Maximum Limit X
64 Voltage Limit X
65 Control Board Over-temperature X X X
