Bell & Gossett P2001487 Technologic Pump Controller User Manual
Page 85
Enclosure size
Power [kW]
Recommended fuse size
Recommended max. fuse
Recommended circuit
breaker Danfoss
Max trip level
[A]
A3
1.1
gG-6
gG-25
CTI25M 10-16
16
1.5
gG-6
gG-25
CTI25M 10-16
16
2.2
gG-6
gG-25
CTI25M 10-16
16
3
gG-10
gG-25
CTI25M 10-16
16
4
gG-10
gG-25
CTI25M 10-16
16
5.5
gG-16
gG-25
CTI25M 10-16
16
7.5
gG-16
gG-25
CTI25M 10-16
16
B2
11
gG-25
gG-63
15
gG-25
gG-63
18
gG-32
22
gG-32
C2
30
gG-40
37
gG-63
gG-80
45
gG-63
gG-100
55
gG-80
gG-125
75
gG-100
gG-160
C3
37
gG-100
gG-125
45
gG-125
gG-160
D
37
gG-125
gG-125
45
gG-160
gG-160
55-75
gG-200
gG-200
90
aR-250
aR-250
110
aR-315
aR-315
132-160
aR-350
aR-350
200
aR-400
aR-400
250
aR-500
aR-500
315
aR-550
aR-550
E
355-400
aR-700
aR-700
500-560
aR-900
aR-900
F
630-900
aR-1600
aR-1600
1000
aR-2000
aR-2000
1200
aR-2500
aR-2500
Table 10.15 525-690 V, Frame Sizes A, C, D, E and F (non UL fuses)
