5 frame sizes and power ratings – Bell & Gossett P2001487 Technologic Pump Controller User Manual
Page 10
Area
Title
Functions
8
Control circuitry
•
Input power, internal
processing, output, and motor
current are monitored to
provide efficient operation
and control
•
User interface and external
commands are monitored and
performed
•
Status output and control can
be provided
Table 1.3 Legend to Illustration 1.3
1.5 Frame Sizes and Power Ratings
References to frames sizes used in this manual are defined in Table 1.4.
Frame Size [kW]
Volts [V]
A2
A3
A4
A5
B1
B2
B3
B4
C1
C2
C3
C4
200-240
0.25-2.2 3.0-3.7
0.25-2.2
0.25-3.7
5.5-11
15
5.5-11
15-18.5
18.5-30
37-45
22-30
37-45
380-480
0.37-4.0 5.5-7.5
0.37-4.0
0.37-7.5
11-18.5
22-30
11-18.5
22-37
37-55
75-90
45-55
75-90
525-600
n/a
0.75-7.5
n/a
0.75-7.5
11-18.5
22-30
11-18.5
22-37
37-55
75-90
45-55
75-90
525-690
n/a
1.1-7.5
n/a
n/a
n/a
11-30
n/a
n/a
n/a
37-90
45-55
n/a
Single phase
200-240
n/a
1.1
n/a
1.1
1.5-5.5
7.5
n/a
n/a
15
22
n/a
n/a
380-480
n/a
n/a
n/a
n/a
7.5
11
n/a
n/a
18.5
37
n/a
n/a
Table 1.4 Frames Sizes and Power Ratings
Introduction
7
1
1
