10 Specifications
10.1 Power-dependent Specifications
10.1.1 Mains Supply 1 x 200-240 V AC
Mains Supply 1 x 200-240 V AC - Normal overload 110% for 1 minute
Frequency converter
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3.0
P3K7
3.7
P5K5
5.5
P7K5
7.5
P15K
15
P22K
22
Typical Shaft Output [HP] at 240 V 1.5 2.0 2.9 4.0 4.9 7.5 10 20 30
IP20/Chassis A3 - - - - - - - -
IP21/NEMA 1 - B1 B1 B1 B1 B1 B2 C1 C2
IP55/NEMA 12 A5 B1 B1 B1 B1 B1 B2 C1 C2
IP66 A5 B1 B1 B1 B1 B1 B2 C1 C2
Output current
Continuous (3 x 200-240 V) [A] 6.6 7.5 10.6 12.5 16.7 24.2 30.8 59.4 88
Intermittent(3 x 200-240 V) [A] 7.3 8.3 11.7 13.8 18.4 26.6 33.4 65.3 96.8
Continuous kVA (208 V AC) [kVA] 5.00 6.40 12.27 18.30
Max. input current
Continuous (1 x 200-240 V) [A] 12.5 15 20.5 24 32 46 59 111 172
Intermittent (1 x 200-240 V) [A] 13.8 16.5 22.6 26.4 35.2 50.6 64.9 122.1 189.2
Max. pre-fuses 1) [A] 20 30 40 40 60 80 100 150 200
Additional specifications
Estimated power loss at rated
max. load [W] 4)
44 30 44 60 74 110 150 300 440
Max. cable size (mains, motor, brake)
[mm 2 ]/(AWG) 2)
[0.2-4]/(4-10) [10]/(7) [35]/(2) [50]/(1)/0 [95]/(4/0)
Weight enclosure IP20 [kg] 4.9 - - - - - - - -
Weight enclosure IP21 [kg] - 23 23 23 23 23 27 45 65
Weight enclosure IP55 [kg] - 23 23 23 23 23 27 45 65
Weight enclosure IP66 [kg] - 23 23 23 23 23 27 45 65
Efficiency 3) 0.968 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
Table 10.1 Mains Supply 1 x 200-240 V AC - Normal Overload 110% for 1 Minute
