Table of Contents
Introduction ..........................................................................................................................5
Quick Start
.............................................................................................................................9
S2000 Miniature Fiber Optic Spectrometer ......................................................11
S2000 Specifications............................................................................................................12
S2000 Board Layout ............................................................................................................13
A/D Converters ..................................................................................................................14
ADC500 ISA-bus A/D Converter..........................................................................................15
ADC1000 ISA-bus A/D Converter (and PC2000) ................................................................19
SAD500 Serial Port Interface...............................................................................................23
DAQ-700 PCMCIA A/D Converter .......................................................................................26
OOIBase32 Operating Software
..............................................................................31
Light Sources ....................................................................................................................33
MINI-D2T Miniature Deuterium Tungsten Light Source.......................................................34
D-1000 Deuterium Light Source ..........................................................................................36
DT-1000 Deuterium Tungsten Halogen Light Source..........................................................38
LS-1 Tungsten Halogen Light Source..................................................................................41
PX-2 Pulsed Xenon Lamp....................................................................................................43
LS-450 Blue LED Pulsed Light Source................................................................................45
R-LS-450 Rack-mount Blue LED Pulsed Light Source .......................................................46
HG-1 Mercury Argon Calibration Source .............................................................................49
LS-1-CAL Calibrated Light Source.......................................................................................52
Sampling Chambers ......................................................................................................54
CUV-UV, CUV-VIS Cuvette Holders ....................................................................................55
CUV-UV-10, CUV-VIS-10 Cuvette Holders .........................................................................57
CUV-ALL 4-way Cuvette Holder ..........................................................................................58
CUV-FL-DA Direct Attach Cuvette Holder ...........................................................................60
ISS Integrated Sampling System .........................................................................................62
ISS-2 Integrated Sampling System......................................................................................64
ISS-UV-VIS Integrated Sampling System............................................................................66
FHS-UV, FHS-VIS In-line Filter Holders ..............................................................................68
LPC Long Pass Flow Cells ..................................................................................................70
CUV-CCE Electrophoresis Sample Cell ..............................................................................72
Sampling Optics ...............................................................................................................74
74-UV, 74-VIS Collimating Lenses.......................................................................................75
74-90-UV Right Angle Reflector...........................................................................................76
74-OPM Optical Post Mount ................................................................................................77
74-ACH Adjustable Collimating Lens Holder .......................................................................78
FVA-UV Fiber Optic Variable Attenuator..............................................................................79
WS-1 Diffuse Reflectance Standard ....................................................................................80
ISP-REF Integrating Sphere ................................................................................................81
FOIS-1 Fiber Optic Integrating Sphere ................................................................................82
