24.3.3 Static Route Configuration Task List
1. Static route configuration
Command Explanation
Global mode
ip route { | /
length>} { | }
[]
no ip route { | /
length>} [ | ]
[]
Set static routing; the no ip route
{ |
prefix>/}
[ |
interface>] [] command
deletes a static route entry
24.3.4 Static Route Configuration Examples
The figure shown below is a simple network consisting of three layer3 switches, the network
mask for all switches and PC is 255.255.255.0. PC-A and PC-C are connected via the static
route set in SwtichA and SwitchC; PC3 and PC-B are connected via the static route set in
SwtichC to SwitchB; PC-B and PC-C is connected via the default route
.
Static Route Configurations
Configuration steps:
Configuration of layer3 SwitchA
Switch#config
Switch (config) #ip route 10.1.5.0 255.255.255.0 10.1.2.2
Configuration of layer3 SwitchC
Switch#config
SwitchB
PC-A:10.1.1.2 PC-B:10.1.4.2
vlan3:10.1.5.1
vlan1:10.1.1.1
vlan2:10.1..2.1
vlan2:10.1.4.1
vlan2:10.1.2.2 vlan1:10.1.3.2
SwitchA
SwitchC
vlan1:10.1.3.1
PC-C:10.1.5.2
