16.0 Registers
(Continued)
16.10.3 Register EEh Special Function Zone 1 Adjustment Offset
Register
Address
Read/
Write
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Default
Value
EEh R/W
Special Function
Zone 1
Adjustment Offset
RES RES Z1_ADJUST 00h
Bit Name R/W Description
5:0 Z1_ADJUST R/W 6-bit signed 2’s complement offset adjustment. This
value is added to all zone 1 temperature
measurements as they are made. All LM93 registers
and functions behave as if the resulting temperature
was the true measured temperature. This register
allows offset adjustments from +31˚C to −32˚C in 1˚C
steps.
7:6 RES R Reserved
16.10.4 Register EFh Special Function Zone 2 Adjustment Offset
Register
Address
Read/
Write
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Default
Value
EFh R/W Special Function
Zone 2
Adjustment Offset
RES RES Z2_ADJUST 00h
Bit Name R/W Description
5:0 Z2_ADJUST R/W 6-bit signed 2’s complement offset adjustment. This
value is added to all zone 2 temperature
measurements as they are made. All LM93 registers
and functions behave as if the resulting temperature
was the true measured temperature. This register
allows offset adjustments from +31˚C to −32˚C in 1˚C
steps.
7:6 RES R Reserved
