16.0 Registers
(Continued)
16.8.10 Register C5h GPO
Register
Address
Read/
Write
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Default
Value
C5h R/W GPO GPO7 GPO6 GPO5 GPO4 GPO3 GPO2 GPO1 GPO0 00h
Bit Name R/W Description
0 GPO0 R/W If set, GPIO_0 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_0 is
being used as an input.
1 GPO1 R/W If set, GPIO_1 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_1 is
being used as an input.
2 GPO2 R/W If set, GPIO_2 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_2 is
being used as an input.
3 GPO3 R/W If set, GPIO_3 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_3 is
being used as an input.
4 GPO4 R/W If set, GPIO_4 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_4 is
being used as an input.
5 GPO5 R/W If set, GPIO_5 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_5 is
being used as an input.
6 GPO6 R/W If set, GPIO_6 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_6 is
being used as an input.
7 GPO7 R/W If set, GPIO_7 will be pulled low. If cleared, the output
is not pulled low. This bit should be 0 if GPIO_7 is
being used as an input.
