16.0 Registers
(Continued)
16.5.4 Register 4Bh H_Error Status 4
Register
Address
Read/
Write
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Default
Value
4Bh RWC
H_Error
Status 4
D2_
ERR
D1_
ERR
DV
DD
P2
_ERR
DV
DD
P1
_ERR
SCSI2
_ERR
SCSI1
_ERR
RES 00h
Bit Name R/W Description
Sleep
Masking
1:0 RES R Reserved N/A
2 SCSI1_ERR RWC SCSI Fuse Error
This bit is set if SCSI_TERM1 has been asserted.
S3, S4/5
3 SCSI2_ERR RWC SCSI Fuse Error
This bit is set if SCSI_TERM2 has been asserted.
S3, S4/5
4 DV
DD
P1_ERR RWC Dynamic Vccp Limit Error.
This bit is set if AD_IN7 (P1_Vccp) did not match the requested voltage as
reported by P1_VID[5:0].
S3, S4/5
5 DV
DD
P2_ERR RWC Dynamic Vccp Limit Error.
This bit is set if AD_IN8 (P2_Vccp) did not match the requested voltage as
reported by P1_VID[5:0].
S3, S4/5
6 D1_ERR RWC Diode Fault Error
This bit is set if there is an open or short circuit on the REMOTE1+ and
REMOTE1− pins.
S3*, S4/5*
7 D2_ERR RWC Diode Fault Error
This bit is set if there is an open or short circuit on the REMOTE2+ and
REMOTE2− pins.
S3*, S4/5*
