14.0 SMBus Interface

(Continued)

Whenever the low byte of a 16-bit register is written, the write
is buffered and does not take effect until the corresponding
high byte is written. If the low byte of a different 16-bit
register is written, the previously buffered low byte of the first
register is discarded. If a device attempts to write the high
byte of a 16-bit register, and the corresponding low byte was
not written (or was discarded), then the LM93 will NACK the
byte.

15.0 Using The LM93

15.1 POWER ON

The LM93 generates a power on reset signal on RESET
when power is applied for the first time to the part.

15.2 RESETS

Upon power up, the RESET output is asserted when the
voltage on the power supply crosses the power-on-reset
threshold level (see Electrical Specifications). The RESET
output is open-drain and should be used with an external
pull-up resistor connected to V

DD

. Once the power on reset

has completed, the RESET pin becomes an input and when
asserted causes the LOCK bit in the LM93 Configuration
register to be cleared. In addition, assertion of RESET
causes the sleep control register to be automatically set to
S4/S5. This causes several error events to be masked ac-
cording to the S4/S5 masking definitions.

Register Types

Power

On Reset

External

Reset

Factory regs

x

Register Types

Power

On Reset

External

Reset

BMC Error Status regs

x

Host Error Status regs

x

Value regs

Limit regs

x

Setup regs

x

LM93 Configuration Lock Bit

x

x

LM93 Configuration GMSK Bit

x (reset)

x (set)

Sleep Mask

x

Sleep State Control

x

Other Mask regs

x

All other registers are not effected by power on reset or
external reset.

15.3 ADDRESS SELECTION

LM93 is designed to be used primarily in dual processor
server systems that may require only one monitoring device.

If multiple LM93 devices are implemented in a system, they
must have unique SMBus slave addresses. See the Section
14.1 SMBUS ADDRESSING
for more information.

The board designer may apply a 10 k

Ω pull-down and/or

pull-up resistors to ground and/or to 3.3V SB V

DD

on the

ADDR_SEL pin. The LM93 is designed to work with resistors
of 5% tolerance for the case where two resistors are re-
quired. Upon the first SMBus communication to the part, the
LM93 assigns itself an SMBus address according to the
ADDR_SEL input.

Address Select

Board Implementation

SMBus Address

less-than 10% of V

DD

Pulled to ground through a 10 k

Ω resistor

0101,100b

≈ V

DD

/2

10 k

Ω (5%) Resistor to 3.3V SB V

DD

and to Ground

0101,110b

greater-than 90% of V

DD

Pulled to 3.3V SB V

DD

through a 10 k

Ω resistor

0101,101b

15.4 DEVICE SETUP

BIOS executes the following steps to configure the registers
in the LM93. All steps may not be necessary if default values
are acceptable.

Set limits and parameters (not necessarily in this order):

Set up Fan control

Set up PWM temperature bindings

Set fan tach limits

Set fan boost temperature and hysteresis

Set the VRD_HOT and PROCHOT PWM ramp control
rate

Enable Smart Tach Mode and Tachometer Input to PWM
binding (required with direct PWM drive of fans)

Set the temperature absolute limits

Set the temperature hysteresis values

Set temperature filtered or unfiltered usage

Set the Zone Adjustment Offset temperature

Set the PROCHOT override and time interval values

Set the PROCHOT user limit

Enable THERMTRIP masking of error events (if GPIO4
and GPIO5 are used as THERMTRIP inputs)

Set voltage sensor limits and hysteresis

Set the Dynamic Vccp offset limits

Set the Sleep State control and mask registers

Set Other Mask Registers (GPI Error, VRDx_HOT, SC-
SI_TERM, and dynamic Vccp limit checking)

Set start bit to select user values and unmask error events

Set the sleep state to 0

Set Lock bit to lock the limit and parameter registers
(optional)

15.5 ROUND ROBIN VOLTAGE/TEMPERATURE
CONVERSION CYCLE

The LM93 monitoring function is started as soon as the part
is powered up. The LM93 performs a “round robin” sampling
of the inputs, in the order shown below. Each cycle of the
round robin is completed in less than 100 ms.

The results of the sampling and conversions can be found in
the value registers and are available at any time.
