16.0 Registers
(Continued)
Lock Register Name Address Default Description
VALUE REGISTERS
Zone 2 (CPU2) Filtered Temp 55h 00h Filtered value of remote thermal diode temperature channel 2
AD_IN1 Voltage 56h N/D Measured value of AD_IN1
AD_IN2 Voltage 57h N/D Measured value of AD_IN2
AD_IN3 Voltage 58h N/D Measured value of AD_IN3
AD_IN4 Voltage 59h N/D Measured value of AD_IN4
AD_IN5 Voltage 5Ah N/D Measured value of AD_IN5
AD_IN6 Voltage 5Bh N/D Measured value of AD_IN6
AD_IN7 Voltage 5Ch N/D Measured value of AD_IN7
AD_IN8 Voltage 5Dh N/D Measured value of AD_IN8
AD_IN9 Voltage 5Eh N/D Measured value of AD_IN9
AD_IN10 Voltage 5Fh N/D Measured value of AD_IN10
AD_IN11 Voltage 60h N/D Measured value of AD_IN11
AD_IN12 Voltage 61h N/D Measured value of AD_IN12
AD_IN13 Voltage 62h N/D Measured value of AD_IN13
AD_IN14 Voltage 63h N/D Measured value of AD_IN14
AD_IN15 Voltage 64h N/D Measured value of AD_IN15
AD_IN16 Voltage 65h N/D Measured value of AD_IN16 (V
DD
3.3V S/B)
Reserved 66h N/D
Current P1_PROCHOT 67h 00h Measured P1_PROCHOT throttle percentage
Average P1_PROCHOT 68h N/D Average P1_PROCHOT throttle percentage
Current P2_PROCHOT 69h 00h Measured P2_PROCHOT throttle percentage
Average P2_PROCHOT 6Ah N/D Average P2_PROCHOT throttle percentage
GPI State 6Bh N/D Current GPIO state
P1_VID 6Ch N/D Current 6-bit VID value of Processor 1
P2_VID 6Dh N/D Current 6-bit VID value of Processor 2
FAN Tach 1 LSB 6Eh N/D Measured FAN Tach 1 LSB
FAN Tach 1 MSB 6Fh N/D Measured FAN Tach 1 MSB
FAN Tach 2 LSB 70h N/D Measured FAN Tach 2 LSB
FAN Tach 2 MSB 71h N/D Measured FAN Tach 2 MSB
FAN Tach 3 LSB 72h N/D Measured FAN Tach 3 LSB
FAN Tach 3 MSB 73h N/D Measured FAN Tach 3 MSB
FAN Tach 4 LSB 74h N/D Measured FAN Tach 4 LSB
FAN Tach 4 MSB 75h N/D Measured FAN Tach 4 MSB
Reserved 76h-77h N/D
LIMIT REGISTERS
Zone 1 (CPU1) Low Temp 78h 80h Low limit for external thermal diode temperature channel 1 (D1)
measurement
Zone 1 (CPU1) High Temp 79h 80h High limit for external thermal diode temperature channel 1
(D1) measurement
Zone 2 (CPU2) Low Temp 7Ah 80h Low limit for external thermal diode temperature channel 2 (D2)
measurement
