16.0 Registers
(Continued)
16.10 OTHER MASK REGISTERS
16.10.1 Register ECh
GPI Error Mask
Register
Address
Read/
Write
Register
Name
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Default
Value
ECh
R/W
GPI Error
Mask
GPI7
_MSK
GPI6
_MSK
GPI5
_MSK
GPI4
_MSK
GPI3
_MSK
GPI2
_MSK
GPI1
_MSK
GPI0
_MSK
FFh
Bit
Name
R/W
Description
0
GPI0_MSK
R/W
When this bit is set, GPI0 error events are masked.
1
GPI1_MSK
R/W
When this bit is set, GPI1 error events are masked.
2
GPI2_MSK
R/W
When this bit is set, GPI2 error events are masked.
3
GPI3_MSK
R/W
When this bit is set, GPI3 error events are masked.
4
GPI4_MSK
R/W
When this bit is set, GPI4 error events are masked.
5
GPI5_MSK
R/W
When this bit is set, GPI5 error events are masked.
6
GPI6_MSK
R/W
When this bit is set, GPI6 error events are masked.
7
GPI7_MSK
R/W
When this bit is set, GPI7 error events are masked.
These bits mask the corresponding bits in the B_ and H_GPI Error Status Registers. They do not effect the GPI State register.
16.10.2 Register EDh
Miscellaneous Error Mask
Register
Address
Read/
Write
Register
Name
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Default
Value
EDh
R/W
Miscellaneous
Error Mask
RES
DVccp2
_MSK
DVccp1
_MSK
SCSI2
_MSK
SCSI1
_MSK
VRD2
_MSK
VRD1
_MSK
3Fh
Bit
Name
R/W
Description
0
VRD1_MSK
R/W
When this bit is set, VRD1_HOT error events are masked.
1
VRD2_MSK
R/W
When this bit is set, VRD2_HOT error events are masked.
2
SCSI1_MSK
R/W
When this bit is set, SCSI_TERM1 error events are masked.
3
SCSI2_MSK
R/W
When this bit is set, SCSI_TERM2 error events are masked.
4
DVccp1_MSK
R/W
When this bit is set, dynamic Vccp limit error events for
AD_IN7 (CPU1) are masked.
5
DVccp2_MSK
R/W
When this bit is set, dynamic Vccp limit error events for
AD_IN8 (CPU2) are masked.
7:6
RES
R
Reserved
