14.0 SMBus Interface
(Continued)
14.5.2 Block Command Code Summary
Block command codes control the block read and write operations of the LM93 as summarized in the following table:
Command Code Name Value Description
Block Write Command F0h SMBus Block Write Command Code
Block Read Command F1h SMBus Block Write/Read Process Call
Fixed Block 0 F2h Fixed Block Read Command Code: address 40h, size 8 bytes
Fixed Block 1 F3h Fixed Block Read Command Code: address 48h, size 8 bytes
Fixed Block 2 F4h Fixed Block Read Command Code: address 50h, size 6 bytes
Fixed Block 3 F5h Fixed Block Read Command Code: address 56h, size 16 bytes
Fixed Block 4 F6h Fixed Block Read Command Code: address 67h, size 4 bytes
Fixed Block 5 F7h Fixed Block Read Command Code: address 6Eh, size 8 bytes
Fixed Block 6 F8h Fixed Block Read Command Code: address 78h, size 12 bytes
Fixed Block 7 F9h Fixed Block Read Command Code: address 90h, size 32 bytes
Fixed Block 8 FAh Fixed Block Read Command Code: address B4h, size 8 bytes
Fixed Block 9 FBh Fixed Block Read Command Code: address C8h, size 8 bytes
Fixed Block 10 FCh Fixed Block Read Command Code: address D00h, size 16 bytes
Fixed Block 11 FDh Fixed Block Read Command Code: address E5h, size 9 bytes
14.5.3 Write Operations
The LM93 supports the following SMBus write protocols.
14.5.3.1 Write Byte
In this operation the master device sends an address byte and one data byte to the slave device, as follows:
1. The master device asserts a START condition.
2. The master sends the 7-bit slave address followed by the write bit (low).
3. The addressed slave device asserts ACK.
4. The master sends a command code (register address).
5. The slave asserts ACK.
6. The master sends the data byte.
7. The slave asserts ACK.
8. The master asserts a STOP condition to end the transaction.
1 2 3 4 5 6 7 8
S Slave
Address
W A Register
Address
A Data
Byte
A P
14.5.3.2 Write Word
In this operation the master device sends an address byte and two data bytes to the slave device, as follows:
1. The master device asserts a START condition.
2. The master sends the 7-bit slave address followed by the write bit (low).
3. The addressed slave device asserts ACK.
4. The master sends a command code (register address).
5. The slave asserts ACK.
6. The master sends the low data byte.
7. The slave asserts ACK.
8. The master sends the high data byte.
9. The slave asserts ACK.
10. The master asserts a STOP condition to end the transaction.
1 2 3 4 5 6 7 8 9 10
S Slave
Address
W A Register
Address
A Data Byte
Low
A Data Byte
High
A P
