54 _____________________________________________________________________________________
DS1876
SFP Controller with Dual LDD Interface
Table 02h, Register A2h–A3h: V
CC
OFFSET
Table 02h, Register A4h–A7h: RESERVED
Table 02h, Register A8h–A9h: BMON2 OFFSET
Table 02h, Register AAh–ABh: PMON2 OFFSET
Table 02h, Register ACh–ADh: BMON1 OFFSET
Table 02h, Register AEh–AFh: PMON1 OFFSET
Table 02h, Register B0h–B3h: PW1
FACTORY DEFAULT
00h
READ ACCESS
PW2 or (PW1 and RWTBL2) or (PW1 and RTBL2)
WRITE ACCESS
PW2 or (PW1 and RWTBL2)
A2h AND B2h MEMORY
Common A2h and B2h memory location
MEMORY TYPE
Nonvolatile (SEE)
A2h, A4h,
A6h, A8h,
AAh, ACh,
AEh
S
S
2
15
2
14
2
13
2
12
2
11
2
10
A3h, A5h,
A7h, A9h,
ABh, ADh,
AFh
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
BIT 7
BIT 0
Allows for offset control of these voltage measurements if desired. This number is two’s complement.
FACTORY DEFAULT
FFFF FFFFh
READ ACCESS
N/A
WRITE ACCESS
PW2 or (PW1 and WPW1)
MEMORY TYPE
Nonvolatile (SEE)
B0h
2
31
2
30
2
29
2
28
2
27
2
26
2
25
2
24
B1h
2
23
2
22
2
21
2
20
2
19
2
18
2
17
2
16
B2h
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
B3h
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT 7
BIT 0
The PWE value is compared against the value written to this location to enable PW1 access. At power-on, the
PWE value is set to all ones. Thus, writing these bytes to all ones grants PW1 access on power-on without writing
the password entry. All reads of this register are 00h.
