52 _____________________________________________________________________________________
DS1876
SFP Controller with Dual LDD Interface
Table 02h, Register 8Eh: RIGHT-SHIFT 2 (RSHIFT 2 )
Table 02h, Register 8Fh: RIGHT-SHIFT 1 (RSHIFT 1 )
Table 02h, Register 90h–91h: RESERVED
FACTORY DEFAULT 00h
READ ACCESS PW2 or (PW1 and RWTBL2) or (PW1 and RTBL2)
WRITE ACCESS PW2 or (PW1 and RWTBL2)
A2h AND B2h MEMORY Common A2h and B2h memory location
MEMORY TYPE Nonvolatile (SEE)
8Eh RESERVED BMON2 2 BMON2 1 BMON2 0 RESERVED PMON2 2 PMON2 1 PMON2 0
BIT 7 BIT 0
Allows for right-shifting the final answer of BMON2 and PMON2 voltage measurements. This allows for scaling the
measurement to the smallest full-scale voltage and then right-shifting the final result so the reading is weighted to the
correct LSB.
FACTORY DEFAULT 00h
READ ACCESS PW2 or (PW1 and RWTBL2) or (PW1 and RTBL2)
WRITE ACCESS PW2 or (PW1 and RWTBL2)
A2h AND B2h MEMORY Common A2h and B2h memory location
MEMORY TYPE Nonvolatile (SEE)
8Fh RESERVED BMON1 2 BMON1 1 BMON1 0 RESERVED PMON1 2 PMON1 1 PMON1 0
BIT 7 BIT 0
Allows for right-shifting the final answer of BMON1 and PMON1 voltage measurements. This allows for scaling the
measurements to the smallest full-scale voltage and then right-shifting the final result so the reading is weighted to
the correct LSB.
FACTORY DEFAULT
READ ACCESS
N/A
WRITE ACCESS N/A
A2h AND B2h MEMORY N/A
MEMORY TYPE N/A
These registers are reserved.
