DS1876
SFP Controller with Dual LDD Interface
Lower Memory, Register 60h–61h: TEMP VALUE
Lower Memory, Register 62h–63h: V CC VALUE
FACTORY DEFAULT 0000h
READ ACCESS All
WRITE ACCESS N/A
A2h AND B2h MEMORY Common A2h and B2h memory location
MEMORY TYPE Volatile
60h S 2 6 2 5 2 4 2 3 2 2 2 1 2 0
61h 2 -1 2 -2 2 -3 2 -4 2 -5 2 -6 2 -7 2 -8
BIT 7 BIT 0
Signed two’s complement direct-to-temperature measurement.
POWER-ON VALUE 0000h
READ ACCESS All
WRITE ACCESS N/A
A2h AND B2h MEMORY Common A2h and B2h memory location
MEMORY TYPE Volatile
62h 2 15 2 14 2 13 2 12 2 11 2 10 2 9 2 8
63h 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
BIT 7 BIT 0
Left-justified unsigned voltage measurement.
