DS1876
SFP Controller with Dual LDD Interface
Table 02h, Register 92h–93h: V
CC
SCALE
Table 02h, Register 94h–97h: RESERVED
Table 02h, RegisteR 98h–99h: BMON2 SCALE
Table 02h, Register 9Ah–9Bh: PMON2 SCALE
Table 02h, Register 9Ch–9Dh: BMON1 SCALE
Table 02h, Register 9Eh–9Fh: PMON1 SCALE
Table 02h, Register A0h–A1h: INTERNAL TEMP OFFSET
FACTORY CALIBRATED
READ ACCESS
PW2 or (PW1 and RWTBL2) or (PW1 and RTBL2)
WRITE ACCESS
PW2 or (PW1 and RWTBL2)
A2h AND B2h MEMORY
Common A2h and B2h memory location
MEMORY TYPE
Nonvolatile (SEE)
92h, 94h,
96h, 98h,
9Ah, 9Ch,
9Eh
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
93h, 95h,
97h, 99h,
9Bh, 9Dh,
9Fh
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT 7
BIT 0
Controls the scaling or gain of the full-scale voltage measurements. The factory-calibrated value produces an FS
voltage of 6.5536V for V
CC
and 2.5V for BMON2, PMON2, BMON1, and PMON1.
FACTORY CALIBRATED
READ ACCESS
PW2 or (PW1 and RWTBL2) or (PW1 and RTBL2)
WRITE ACCESS
PW2 or (PW1 and RWTBL2)
A2h AND B2h MEMORY
Common A2h and B2h memory location
MEMORY TYPE
Nonvolatile (SEE)
A0h
S
2
8
2
7
2
6
2
5
2
4
2
3
2
2
A1h
2
1
2
0
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
BIT 7
BIT 0
Allows for offset control of temperature measurement if desired. The final result must be XORed with BB40h
before writing to this register. Factory calibration contains the desired value for a reading in degrees Celsius.
