______________________________________________________________________________________ 33
DS1876
SFP Controller with Dual LDD Interface
Lower Memory, Register 64h–65h: BMON VALUE
Lower Memory, Register 66h–67h: PMON VALUE
Lower Memory, Register 68h–6Dh: RESERVED
POWER-ON VALUE 0000h
READ ACCESS All
WRITE ACCESS N/A
A2h AND B2h MEMORY Different A2h and B2h memory locations
MEMORY TYPE Volatile
64h, 66h 2 15 2 14 2 13 2 12 2 11 2 10 2 9 2 8
65h, 67h 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
BIT 7 BIT 0
Left-justified unsigned voltage measurement.
POWER-ON VALUE
READ ACCESS
N/A
WRITE ACCESS N/A
A2h AND B2h MEMORY N/A
MEMORY TYPE N/A
68h, 6Dh 0 0 0 0 0 0 0 0
BIT 7 BIT 0
These registers are reserved. The value when read is 00h.
