• To select non contiguous elements, keep CTRL pressed while selecting the
elements.
• To select a group of clips, click the group heading.
2.5. Status Bar
2.5.1. Introduction
This area displays information regarding lock on air position, Auxiliary Clip, End Cue, As
run log, Post-Roll and the number of elements present in the playlist.
The Total playlist duration, the END CUE area, the As Run Log area and the post-Roll
area are displayed only if this has been set under Tools > Settings > Playlist > Colors.
2.5.2. Lock On-Air Position Button
changes to
This option is used to keep the on-air element always visible in the playlist panel.
The "lock on-air position" mode is activated or de-activated by clicking the Lock on-air
position button. When activated, the button background color becomes blue.
The mode is automatically reset when:
• the user scrolls in the playlist, or
• a clip, a train, a timeline or a growing clip is loaded on the channel, and consequently,
the playlist is unloaded.
The Lock on-air button is dimmed and unavailable in each of the following cases:
• no channel is associated to the playlist panel
• no playlist is loaded
• the on-air element is not visible on the playlist panel.
2.5.3. Auxiliary Clip Name Area
This area indicates whether an auxiliary audio clip is associated to the playlist or not.
If an auxiliary clip is associated, the area displays the name and LSM ID of the clip.
If no auxiliary clip is associated, the area displays "No Auxiliary clip":
