Options for Camera Angle Selection
• If PREF is 'ON', the preferred camera angle of the clip appears on the primary
channel, the secondary camera angle on the next controlled channel, and the other
camera angles on the next channels in alphabetical order.
◦ Example: If the preferred camera angle for clip 124 is camera C, when loading the
clip, 124C is loaded on the primary channel, whatever the camera present on that
channel before loading the clip.
• If PREF is 'OFF', the camera angle will be the same as the one already present on
each controlled channel. If that camera angle does not exist, the first available camera
angle of the clip is used.
◦ Example: If camera B is the current camera on the primary channel, when calling
clip 124, it is 124B that appears on the primary channel, even if it is not the
preferred camera angle.
• When the operator is controlling only one channel (such as with PRV CTL), the clip
appears at that location only. In the case of a clip containing a single camera angle (so
only an 'A', 'B', 'C', or 'D' clip), when in full control of all outputs, the clip recalled will
appear on the primary channel.
Growing Clips
You can recall and play back growing clips, or clips that are in the process of being
created on a disk.
• As long as the OUT point of a growing clip is not available on the EVS server, the LED
corresponding to the growing clip location blinks green when it is called and red when
it is loaded on the Remote Panel. The clip LED will no longer blink as soon as both IN
and OUT points are available on the EVS server.
• If the play reaches the end of the available material, it freezes until new material is
available for play back. As soon as new material is available, the play resumes.
• When the OUT point of the clip is known, the remaining time is displayed, otherwise
the remaining time display is '--:--:--:--' until the entire clip is copied.
