2. Working Interfaces
2.1. Overview
Several User Interfaces
The EVS server can be operated from several user interfaces that can work
complementarily:
• VGA interface
• Remote Panel interface
• LSM.Connect application
• Xscreen application
Initial Configuration
Warning
Before you start using Multicam with the XSense Remote Panel, you need to
ensure that the parameters are properly set for the configuration line you want to
run.
If clips are stored with certain parameters and the operator wishes to change the
parameter values afterwards, those clips and playlists will not change. It is thus
important to set the requested parameters first.
The Multicam Setup and Configuration modules of the VGA interface are used for
configuration and maintenance operations. A web-based user interface for distant
configuration is also available. A Technical and Operational Setup menus are also
available from the Remote Panel to configure the most important Multicam parameters.
The Multicam Setup window is used to select the configuration you want to run Multicam
with, since EVS disk recorders have the ability to run various configurations.
The Multicam Configuration window and included tabs allow users to define the channel
configuration associated to a configuration line, audio and video parameters, and all
operational parameters.
You will find detailed information on Multicam configuration from the VGA and from the
Remote Panels in the EVS Server Configuration manuals.
