5.7.4. Swapping Audio Tracks
Introduction
The swap audio tracks mode allows swapping audio tracks between two points in a
playlist. This function can only be executed on the Remote Panel.
• In four-track mode, the “auto” mode replaces audio tracks 1 & 2 by audio tracks 3 & 4
in four audio mode.
• It replaces audio track 1 by audio track 2 in stereo mode.
• The manual mode lets you choose which tracks to replace.
Note
In 8- and 16-track modes, you only have access to the manual mode.
Enabling the Audio Swap Mode
To enable the Audio Swap mode, proceed as follows:
1. Enter the Setup menu.
2. Select the Swap audio tracks parameter value in the Operational Setup menu (p.3.2
F4).
3. Choose the “Auto” or “Manual” value.
Note
Please note that the Advanced audio editing parameter has to be enabled in the
Operational Setup menu (p.3.2 F2). This option requires a specific license code.
If that code is not installed on the server, this option cannot be turned on.
Swapping Audio Track in Auto Mode
To perform a swap audio track in Auto mode, proceed as follows:
1. In Playlist Edit mode, select the Video Base mode (V Base) by pressing SHIFT+. The
LCD screen will now display additional function:
PL11 LSM01 Paola LOC TDUR=00:00:02:22
111A/04 Clipname012 00:00:29 Unk W00:10
112B Clipname456 00:53:29 Unk W00:10
112B/02 Clipname891 00:53:29 Unk W00:10
V Base A Base Swap
A Advanc A Delay A FX DUR A Split
2. Press the Swap function (SHIFT+D).
3. Jog your playlist until you reach the point where you want to change the audio tracks.
