How to Enter the PGM+PRV Mode
To enter the 1PGM+PRV mode, press A from the Main menu. The Remote Panel will then
display the following screen:
PGM1 CAM A *PRV1* CAM B
Aud.Met. PgmSpd PostRoll
Mix Sw to IN Search Pref
P.1 B.1 Clips: LOCAL Records: LOCAL
PL 11: <
Msg
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
At least 2 playback channels must be available to run this configuration.
This mode allows the operator to make replays with/or without transition effects between
all outputs. A string of replays can be put together and played back at the operator’s
discretion.
The LCD display is divided in two menus controlled by soft keys (A, B, C, D). To gain
access to the upper menu, press MENU from the Remote Panel.
3.2.2. 1PGM+PRV Primary Menu Controls
Introduction
The primary menu in 1PGM+PRV mode, illustrated below, gives access to the functions
detailed in the following paragraphs:
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
CAM A / B / C / D
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
If PRV CTL is 'OFF', select the camera to assign to the PGM output. This camera key
will be highlighted in the menu.
If PRV CTL is 'ON', select the camera to assign to the PRV output. This camera key will
be highlighted in the menu.
