The Main menu has special function key operations as shown above, as well as the “soft”
keys options to enter 1PGM, 1PGM+PRV, 2PGM, or 3PGM modes (if available) and to
enter the Setup menu to configure your remote controller or to add special functions to
your application.
Note
If 2 channels are available for the first Remote Panel, the B key will display 2
PGM. If 3 channels are available, the B key will display 3 PGM.
Returning to the Main Menu
From any section of the application, except Playlist mode, press SHIFT+MENU on the
first Remote Control panel to return to the main menu.
Function Keys in the Main Menu
Select the corresponding Function key (F_ key), and then press ENTER to validate the
selection.
Function Key Use
F1 to F4 If desired, the Multicam system can be run using 1, 2, 3 or 4 EVS
Remote Panels. Depending on the number of play channels
available in the current configuration, 1-, 2-, 3- or 4- Remote
modes will be available from the main menu.
F1: 1 Remote One Remote Panel is used in the configuration
F2: 2 Remotes Two Remote Panels are used in the configuration.
If 4 play channels are available, when selecting the 2 Remotes
mode, the operator can choose between two configurations:
• 2 play channels for each remote:
In this configuration, each Remote Panel can select
PGM+PRV or 2PGM mode. Each Remote Panel can
manage video transitions (cut, mix, wipe) in PGM+PRV and
playlist modes.
• 3 play channels for the 1 st remote and 1 play channel for the
second remote.
In this configuration, the 1
st remote can select PGM+PRV or
3PGM mode and can manage video transitions. The 2 nd
remote is forced to 1PGM mode and can only handle cut
transitions.
F3: 3 Remotes Three Remote Panels are used in the configuration.
F4: 4 Remotes Four Remote Panels are used in the configuration.
F5: Char. On/Off Enables or disables the on-screen display (Timecode, Clip ID…)
on the output monitors.
F6: Exit Exits the Multicam software and returns to the EVS Menu.
OPERATION MANUAL XSense 11.02
2. Working Interfaces 11
