The LCD display returns to the normal mode and the names of the remote systems are
now displayed after the Page and Bank information as illustrated hereunder:
PGM1 112B/04 *PRV1* CAM B
AUX Clip
MIX Sw to IN PGMSpd PREF
P.1 B.1 Clips: ALBERT Records: MICHEL
PL 11: <
Msg:
LOCAL SYNC PRV
CAM A CAM B CAM C CAM D
Connection Modes
Local mode
The local system is identified with the 'Local' sign after the name of the system as
illustrated in the previous figure.
Press the A key to activate the Local mode and have direct access to the Local mode.
This command is highlighted when Local mode is activated.
Clips Mode
Press the B key to activate the Clips function.
In this mode, you can connect to the clip banks of another EVS server connected to the
network. In other words, the VGA clip screen and the F_ keys of the Remote Panel show
the clips from the selected EVS server.
If you press the RECORD key, you go in Live mode on the local record trains.
Records Mode
When you select one of the EVS server in the Network menu, you connect the record
trains to this EVS server. This means that the next time you press the C key for the
Record function, the active channels will go in Live mode (or Near Live mode for remote
trains) on the record trains of the selected EVS server.
The clips remain connected to the EVS server they were connected to.
Clips+Records Mode
Press the D key that activates the Clip+Rec function. In this mode, you can connect both
to the clips banks and to the record trains of a remote server.
The VGA clip screen and the F_ keys of the Remote Panel show the clips from the
selected server.
The next time you press the RECORD key, the active channels will go in Live mode (or
Near Live mode for remote trains) on the record trains of the selected EVS server.
