Issue 5.8.B IPDirector Version 5.8 – User Manual – Part 6: Playout – Playlist Panel
EVS Broadcast Equipment – July 2010
72
Transition category. Refer to section 1.9.3 ‘Default Transition Settings’ on page
123 for details on the settings options.
Seven video effects are available. Audio effects depend on the applied video
effect. The table below summarizes the possible associations of video and audio
effects.
Audio Effect Cut Mix Fade
from
Mute
Fade to
Mute
V Fade
to/from
Mute
Video Effect
Cut √ √
Mix √
Wipe Left -> Right √
Wipe Right -> Left √
Fade from Black √
Fade to Black √
V Fade to/from Black √
Note
It is not allowed to define both A/V effect and a still/start mode option for
a transition between elements.
Two options are available to define audio and/or video transition effect for a
playlist element:
• using a macro command, previously configured to correspond to a specific
effect with specific parameters. Refer to section 1.7.9 ‘Applying a Macro
Command to Trigger Playout Effects’ on page 94 for information on using macro
commands and to section 1.9.5 ‘Playlist Macro Commands Settings’ on page
127 for information on configuring macro commands.
• defining audio and/or video effect and duration by selecting options from a list
or entering duration values in the grid. Related procedure and windows are
described hereafter.
In this case, the audio and video effects can be defined in two different ways:
o
through the Playlist Element contextual menu
o
by direct entry/selection in the playlist grid
