Issue 5.8.B
IPDirector Version 5.8 – User Manual – Part 6: Playout – Playlist Panel
EVS Broadcast Equipment – July 2010
20
S
ELECTION OF
E
LEMENTS
The selection of elements in a playlist follows the selection rules applicable in any
Windows-based application.
Selecting elements in a playlist is performed as follows:
•
To select contiguous elements, click the first element, press SHIFT and click
the last element.
•
To select non contiguous elements, keep CTRL pressed while selecting the
elements.
•
To select a group of clips, click the group heading.
1.2.5 S
TATUS
B
AR
L
OCK
O
N
-A
IR
P
OSITION
B
UTTON
changes to
This option is used to keep the on-air element always visible in the playlist panel.
The ‘lock on-air position’ mode is activated or de-activated by clicking the Lock
on-air button. When activated, the button background color becomes orange.
The mode is automatically reset when:
•
the user scrolls in the playlist, or
•
a clip, a train, a timeline or a growing clip is loaded on the channel, and
consequently, the playlist is unloaded.
The Lock on-air button is dimmed and unavailable in each of the following cases:
•
no channel is associated to the playlist panel
•
no playlist is loaded
•
the on-air element is not visible on the playlist panel.
