Duct Smoke Detector Table of Contents | en 53
Bosch Sicherheitssysteme GmbH Installation guide F.01U.033.733 | 5.0 | 2011.11
Table of Contents
1 Product description 54
1.1 Scope of delivery 54
1.2 Accessories 54
2 Product overview 55
3 Installation/configuration notes 56
3.1 Prerequisite 56
3.2 Installation position 57
3.3 Housing position 57
4 Installation 58
4.1 Sample tube 58
4.2 Installing the FAD-420-HS-EN 59
4.3 Installing the FAD-RB-DIBT 63
4.4 Installing the FAD-O420 Smoke Detector 64
5 Connection 65
6 Configuration 66
6.1 Jumper setting 66
6.2 Checking the airflow 66
6.3 Detector test 67
7 Technical data 68
