Duct Smoke Detector
Product overview | en
55
Bosch Sicherheitssysteme GmbH
Installation guide
F.01U.033.733 | 5.0 | 2011.11
–
D344-1.5 Sample Tube, 0.46 m
–
D344-3 Sample Tube, 0.91 m
–
D344-5 Sample Tube, 1.52 m
–
FAD-RB-DIBT Relay Board
–
FAA-420-RI Remote Indicator
Note: Cannot be connected if the FAD-RB-DIBT Relay
Board is installed!
–
Air filter (20 units) for D344-TF Sample/Ventilation Tube
2
Product overview
Pos. Description
A
Ventilation duct detector housing
B
Detector base for the FAD-O420 Smoke Detector
C
Mounting flange for ventilation tube
D
Mounting flange for sample tube
E
Connection board
